MONDRAKER Chrono Carbon R, nimbus grey/black/yellow, 2024 Velikost L
Description and parameters
MONDRAKER Chrono Carbon R, nimbus grey/black/yellow, 2024
ParametersAdd to Compare
Root
E-shop
Root
B2B
Shop type
SML
Activity
cycling PCI
Category
Hardware
SEO description
Horské kolo
Group
bicycle-HW
Subgroup
mtb-HW BIC
Eshop size group
size_frame
Size
L
Supplier size group
supplier_size_hardware
Filter of specific parameters
HW
Přehazovačka
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Hlavové složení
Onoff internal IS52 1-1/2 head tube, ACB sealed bearings, top 51,8x40 45°x45°, bottom 51,8x40 36°x45°
Vidlice
Fox 32 29 Float GRIP EVOL Rhythm, 120mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: remote 2pos Push-to-unlock, low-speed rebound, air preload Fox single pull
Velikosti
S: 395mm / M: 430mm / L: 470mm / XL: 520mm
Rám
Chrono 29 Stealth full Carbon, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable routing, Boost 12x148mm rear axle, dedicated 1X drivetrain design, Flatmount brake compatible,
Sedlo
Mondraker MDK Series, SRX, steel rail
Materiál rámu
carbon
Dráty
Mavic straight-pull double butted, contactless lacing
Typ vidlice
SUSPENSION FORK
Zadní brzda
Sram Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brzdové páčky
Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
Představec
MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5?, length: S size: 50mm, M size: 50mm, L size: 60mm, XL size: 70mm
Převodník
34T, steel, X-Sync 2
Sedlovka
Onoff Pija dropper internal, diameter 31.6mm, Universal lever, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
Středové složení
Sram DUB BSA, sealed bearings, 73mm
Přední brzda
Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Velikost kol
29
Kliky
Sram NX Eagle, 12s, Boost, DUB axle, Direct Mount chain ring, S size: 170mm M size: 175mm L size: 175mm XL size: 175mm, CL 55
Počet převodů
1X12
Ráfky
Mavic Crossmax 29, 25mm internal width, welded rim, hookless, tubeless ready, 24 spokes
Řídítka
Onoff Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 760mm, 9? backsweep, 0? upsweep, 31.8mm barbore
Řetěz
Sram SX Eagle, 12s, Powerlock
Zadní náboj
Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts, HG freehub
Přední náboj
Mavic, Boost 15x110mm, IS 6 bolts
Zadní plášť
Maxxis Ardent 29x2.40, Dual compound, EXO, tubeless ready, 60TPI, folding bead
Řadící páčka
Sram Trigger NX Eagle, 12s, X-Actuation 1:1
Přední plášť
Maxxis Ardent 29x2.40, Dual compound, EXO, tubeless ready, 60TPI, folding bead
Patka přehazovačky
Sram UDH
Kazeta
Sram PG-1230, 11-50T, 12s
Hmotnost
12,1 kg
